Custom Bike Rack

Description

High quality Unitran custom bike rack

Subject A:

• 4 only – Unirak End Frame – 24″ x 102″
• Typical Unirak End Frame construction
• Powder coated in Unitran safety blue

Subject B:

• 4 only – Unirak Box Beam – 4″ x 70″
• Typical Unirak Box Beam construction
• Powder coated in Unitran safety blue

Subject C:

• 4 pair only – Unirak Cantilever Arm – 20.4375″
• ERW SQ. 2″ x 2″ x .065″ tube with double Unirak brackets
• 4 left, 4 right
• Powder coated in Unitran safety blue

Subject D:

• 4 only – 2″ x 2″ x 108″ tube
• ERW SQ. 2″ x 2″ x .065″ x 108″
• Cut to length and deburred
• Powder coated in Unitran safety blue

Subject E:

• 16 only – Mounting Cleat for subject D
• 1 1/2″ x 1 1/2″ x 1/8″ angle iron with two 1/4″ holes
• Powder coated in Unitran safety blue

Reference #SJM2374

Bike Storage Rack Components

Bike Storage Rack Drawing
